Reed Switches	Proximity Switches	Shock Sensors

Part no.	Contract type	Contact capacity	Outer dimensions (mm)			Features (Contact material)
Part no.	Contract type	Contact capacity	Glass tube length	Glass tube diameter	Total length	Features (Contact material)
ORD213	1A	1W	7.0max	Ø1.80max	35.8 ± 0.3	Super ultra-miniature (Rh)
ORD213S-1	1A	1W	7.0max	Ø1.80max	13.0	Super ultra-miniature SMD(Rh)
ORD211	1A	1W	10.0max	Ø2.0max	35.7 ± 0.3	Ultra-miniature (Rh)
ORD219	1A	10W	12.0max	Ø2.00max	44.3 ± 0.3	Miniature high-performance (Rh)
ORD221	1A	10W	13.0max	Ø2.30max	44.2 ± 0.3	Miniature off-set type (Rh)
ORD2221	1A	10W	13.0max	Ø2.30max	56.7 ± 0.3	Miniature off-set type long lead(Rh)
ORD228VL	1A	10W	14.0max	Ø2.20max	44.3 ± 0.3	Miniature high-performance (Rh)
ORD228S-1	1A	10W	14.0max	Ø2.20max	19.6 ± 0.3	Miniature high-performance SMD (Rh)
ORD229	1A	DC50W/AC70W	21.0max	Ø2.75max	55.4 ± 0.3	High breakdown voltage (Rh)
ORD2210	1A	DC50W/AC70W	21.0max	Ø2.75max	55.4 ± 0.3	High power (Rh)
ORD2210V	1A	100W	21.0max	Ø2.75max	55.4 ± 0.3	Vacuum, high power (Rh)
ORD2211	1A	50W (12V 3.4W lamp)	16.5max	Ø2.80max	44.1 ± 0.3	Lamp load (Rh)
ORD234	1A	10W	21.0max	Ø3.50max	43.4 ± 0.3	Long-life (Rh)
ORT551	1C	3W	14.0max	Ø2.54max	N.O51.6 ± 0.3 N.C56.1 ± 0.3	Ultra-miniature transfer (Rh)
ORD311	1A	10W	7.0max	Ø1.80max	35.8 ± 0.3	Super ultra-miniature long-life (Ir)
ORD312	1A	30W	12.0max	Ø2.00max	44.3 ± 0.3	High-power long-life (Ir)
ORD324	1A	10W	14.0max	Ø2.2max	44.3 ± 0.5	High-power long-life (Ir)
RA-901	1A	10W	2.5 ± 0.1(W)	2.5 ± 0.1(H)	19.5 ± 0.2(L)	Miniature SMD (Molded type)
RA-903	1A	1.0W	2.1 ± 0.1(W)	2.1 ± 0.1(H)	12.3 ± 0.2(L)	Ultra-miniature SMD (Molded type)
